Ultra Premium Blood Pressure Monitorfeaturing ComFitTMCuffModel HEM-775INSTRUCTION MANUALESPAÑOLENGLISHHEM-775 IM Final.qxd 11/16/06 4:03 PM Page 1

10UNIT DISPLAYDiastolic Blood PressureSystolic Blood PressureMovement SymbolPulse DisplayDate/Time DisplayLow Battery IndicatorDeflation SymbolMorning

11IRREGULAR HEARTBEAT SYMBOL ( )When the monitor detects an irregular rhythm two or more times duringthe measurement, the Irregular Heartbeat Symbol (

The American Heart Association1recommends the following guidelinefor upper limit of normal for home blood pressure readings:AHA Home Guideline for Upp

HEARTBEAT SYMBOL ( )TAKING A MEASUREMENTThe Heartbeat Symbol flashes on the display during the measurement.The Heartbeat Symbol flashes at every heart

1. Press the ▼ indicator on the battery coverand slide the cover off in the direction ofthe arrow.2. Install 4 “AA” size batteries so the +(positive)

BATTERY REPLACEMENTWhen the Low Battery Indicator appears on the display screen turn themonitor off and remove all the batteries. Replace with four ne

Use only the authorized Omron AC Adapter, Model Number HEM-ADPT1,with this monitor.We recommend you install the batteries even if the AC Adapter is us

TO CONNECT THE AC ADAPTER① Insert the AC Adapter Plug into the AC Adapter Jack on the back side of the monitor as illustrated.② Plug the AC Adapter in

18Set the monitor to the current date and time before taking ameasurement for the first time. If the date and time are not set correctly,the measureme

19SETTING THE DATE AND TIME2. SETTING THE YEARThe year can be set between 2007 and2030. When the display reaches 2030,it will return to 2007.Press the

2Before Using the MonitorIntroduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4Safety Info

204. SETTING THE DAYPress the Memory button ( ) to advance by increments of one day.Press the SET button to set the current day.The hour flashes on th

RESETTING THE DATE AND TIMETo adjust the date or time after it has been setup when you first use the unit. Start with the monitor in the off position.

CAUTIONRead all of the information in the instruction manual and any otherliterature in the box before operating the unit.CAUTIONThis device is intend

233. Sit in a chair with your feet flat on the floor. Place your left arm on a table so the cuff is level with your heart.4. Hold the grip on the cuff

246. Apply the cuff to your left upper arm so the blue strip is on the insideof your arm and aligned with your middle finger. The air tube runsdown th

APPLYING THE CUFF ON THE RIGHT ARMWhen taking a measurement using the right arm use this instruction for Step 6 on page 24.Apply the cuff to your righ

The monitor is designed to take measurements and store themeasurement values in the memory for two people using USER ID A and USER ID B.The monitor ca

3. Inflation stops and the measurement is started. When themeasurement is completed, your blood pressure and pulse rate appearon the display.SELECTING

SELECTING THE TruReadTMMODE1. Select your USER ID (A or B).2. Press and hold the SET button.The TruReadTMsymbol and the oFF setting appears on the dis

4. Press the SET button to confirm the change.The number of seconds between each measurement is displayed.NOTE: The default value between each measure

Taking a Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26Using the Guest Mode . . . . . . . . . . . .

7. If the date and time are correct, press theSTART/STOP button to turn the monitoroff.To change the date and time refer to page18, SETTING THE DATE A

2. Press the START/STOP button.All symbols appear on the display. The USER ID Symbol youselected flashes on the display. The cuff starts to inflate au

4. When the measurement is complete, the arm cuffcompletely deflates. Your blood pressure and pulserate are displayed. 5. Press the START/STOP button

USING THE TruReadTMMODE1. Select your USER ID (A or B).2. Press the START/STOP button.All symbols appear on the display. The USER ID Symbol youselecte

The second measurement is complete, waiting to start the nextmeasurement.The consecutive measurements are complete. The average for threemeasurements

TAKING A MEASUREMENT35SPECIAL CONDITIONSCAUTIONInflating to a higher pressure than necessary may result in bruisingwhere the cuff is applied.If your s

The monitor is designed to store the blood pressure and the pulse rate inthe memory for two people (USER A and USER B) every time ameasurement is comp

TO DISPLAY THE MEASUREMENT VALUES1. Select your USER ID (A or B).2. Press the Memory button ( ).The Average Symbol ( ) appears on the display when the

3. Press the Memory button ( ) to display the most recent set ofmeasurement values on the screen. The values are displayed from themost recent to the

MORNING AND EVENING AVERAGESThe monitor calculates and displays a weekly average for measurementstaken in the morning ( ) and evening ( ). The monitor

4Thank you for purchasing the Omron®HEM-775 IntelliSense®Automatic Blood Pressure Monitor with ComFitTMCuff.INTRODUCTIONFill in for future reference.D

TO DISPLAY MORNING AND EVENING AVERAGES1. Select your USER ID (A or B).2. Press the Morning Average button( ) or the Evening Averagebutton ( ). The a

USING THE MEMORY FUNCTION41DISPLAY COMBINATIONSIn addition to the Morning Average and Evening Average Symbols, the monitor may also display the Mornin

The Morning Hypertension Symbol ()appears if the weekly averagefor morning measurements is above 135/85.In this case the Morning Hypertension Symbol (

43To keep your digital blood pressure monitor in the best condition andprotect the unit from damage, follow the directions listed below:Close the moni

Remove the batteries if the unit will not be used for three months orlonger. Always replace all the batteries with new ones at the same time. Use th

45SYMBOL CAUSE CORRECTIONCuff under-inflated.Cuff not appliedcorrectly.Single ModeRemove the arm cuff. Read,“Taking a Measurement”. Take another measu

46ERROR INDICATORS AND TROUBLESHOOTING TIPSPROBLEM CAUSES AND SOLUTIONSNo power.No display appears on the unit.Replace all four batteries with newones

47FCC STATEMENTNote:POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only)This product has been tested and found to comply with the limits for

WARRANTY48Your HEM-775 IntelliSense®Automatic Blood Pressure Monitor, excluding thearm cuff, is warranted to be free from defects in materials and wor

49Model: HEM-775Display: LCD Digital DisplayMeasurement Range: Pressure: 0 to 299 mmHg, Pulse: 40-180/min.Accuracy/Calibration: Pressure: ±3mmHg or 2%

5To assure the correct use of the product basic safety measures shouldalways be followed including the warnings and cautions listed in thisinstruction

NOTES50HEM-775 IM Final.qxd 11/16/06 4:03 PM Page 50

NOTES51HEM-775 IM Final.qxd 11/16/06 4:03 PM Page 51

Manufactured by OMRON HEALTHCAREMade in ChinaDistributed by:OMRON HEALTHCARE, INC.1200 Lakeside DriveBannockburn, Illinois 60015www.omronhealthcare.co

OPERATING THE DEVICE (continued)Read the Special Conditions section (page 35) of the instructionmanual if your systolic pressure is known to be more t

CARE AND MAINTENANCEDo not subject the monitor to strong shocks, such as dropping theunit on the floor.Do not submerge the device or any of the compon

8BEFORE TAKING A MEASUREMENTTo ensure a reliable reading follow these recommendations:1. Avoid eating, drinking alcohol, smoking, exercising, and bath

9KNOW YOUR UNITMain Unit:Air JackBattery CompartmentStart/Stop ButtonUSER ID Selection SwitchUSER ID Symbol (A or B)Monitor CoverCuff CompartmentMorni
